400W Crystalline Solar Power Supply System
Products advantages
[Product Composition]：
The Standard : Solar Panels + Power Box + Cable Connection
The Options: LED lights
[Descriptions & Advantages]：
The power output is a universal AC output with 4 outlets.
Solar power mater indicator.
The controller of our own research and development is designed for our special solar power box
Anti-overcharge, anti-overdischarge, anti-overload and short-circuit resistance.
Fixed installation and adjustable brackets.
Technical datas
- Specifications of Solar Panel：
- Pmax：270W
- Vmp：35V
- Imp：7.72A
- Voc：41.4V
- Unfolded Size：1480mm*1265mm*780mm (30°)
- Weight：35Kg
- Specifications of Other：
- AC Output：220V/50Hz,400W(Maximum)
- Battery Type： Rechargeable Lead-acid Battery
- Battery Capacity：24V/150Ah
- Size：427mm*545mm*473mm
- Weight：112Kg
