600W Crystalline Solar Power Supply System
Products advantages
[Product Composition]：
The Standard : Solar Panels + Power Box + Cable Connection
The Options: LED Lights + LCD TV
[Descriptions & Advantages]：
Two types of output: a USB charging output interface and 2 universal AC output .
Simple, convenient to carry, easy to operate,etc
Integral panel, Small volume and best working condition
The controller of our own research and development is designed for our special solar power box
Anti-overcharge, anti-overdischarge, anti-overload and short-circuit resistance.
Best light angle and ajustable brackets improve the power production.
The frame of Power box is coated with special rustproof and anti-corrosion multiprocessing to ensure the longer lifespan.
Portable wheel design is for using in different occasions.
[Power plan]：
To the home lighting, for example, the average daily electricity consumption plan is as follows:
(TV 30W * 8h) + (light 5W * 3 * 6h) + (Fan 40W * 5h)= 530Wh
Technical datas
- Specifications of Solar Panel：
- Pmax：145W
- Vmp：18.7V
- Imp：7.76A
- Voc：22.6V
- Folded Size：1480mm*676mm*37mm
- Weight：13.5Kg
- Specifications of Other：
- AC Output：220V/50Hz,600W(Maximum)
- DC Output：DC 5V/1A(USB)
- Battery Type：Rechargeable Lead-acid Battery
- Battery Capacity：12V/100Ah
- Size：493mm*305mm*338mm
- Weight：34Kg
